Standard Customized Durable Shipping Container House

About the Standard Customized Durable Shipping Container House

The Standard Customized Durable Shipping Container House is a HUD-certified residence built by Outback Shipping Containers. Residential framing, insulation, electrical, plumbing and finishes are installed in the factory and inspected before dispatch.

The home uses the recorded modular configuration, with reinforced residential openings and factory-installed framing, insulation, electrical, plumbing and finishes. Heavy-gauge CorTen steel frame with insulated wall, floor & roof panels

Features & Inclusions

• • Customised 20ft High Cube steel shell — 19'-6" x 7'-6" x 8'-10" clear inside
• • Supplied as an empty shell: no partitions, lining, bathroom or kitchen
• • Double-leaf steel end door with lever handle, opens to 270 degrees
• • Double-leaf hinged access panel on the long wall for equipment loading
• • Full-height fixed weather-louvre bank with insect mesh for passive ventilation
• • Flush steel personnel door with vision light, leaf louvre and perforated vent
• • Bolted service hatch and six-box cable-entry rack for glanded cable entry
• • Marine-grade plywood deck on 4in steel cross-members at 12in centres
• • Industrial white enamel over zinc-rich primer, inside and out
• • Fully customisable: insulation, lining, windows, electrics and HVAC quoted separately

Specifications

Catalog Model Number

OSC-HM-20-ABA0CC76

SKU

OSC-GEN-5F7755

Container / Unit ID

OSC-CID-A0CC76

Product Class

Container Home

Condition

New

Exterior Length

20'0"

Exterior Width

8'0"

Exterior Height

8'6"

Frame / Structure

Steel cargo-container or modular frame; alterations and reinforcement vary by model

Wall Construction

Steel exterior shell; interior wall build-up is model-specific

Roof Construction

Steel roof assembly; penetrations and added roof systems are listed when fitted

Floor Construction

Finished floor assembly varies with the selected build

Interior Finish

Painted drywall or shiplap walls, LVP flooring, quartz or butcher-block counters

Insulation

Closed-cell spray foam (R-19 walls, R-30 roof equivalent)

Doors

Insulated dual-pane windows, insulated steel entry door, security shutters optional

Plumbing

Full bathroom and kitchen rough-ins, on-demand water heater, PEX supply lines

HVAC

Mini-split heating & cooling system, sized to floor plan

Electrical Supply Phase

Single-phase (1-phase)

Required Voltage

110V/220V

Electrical Service

110V/220V pre-wired, breaker panel, LED lighting, exterior weatherproof outlets

Wind Zone

Zone II (Zone 2)

Wind Rating

120 mph (miles per hour), 3-second gust

HUD Code Reference

24 CFR 3280 — Manufactured Home Construction and Safety Standards; wind provisions: 24 CFR 3280.305

Code Scope

This container home is HUD certified and built to the HUD Manufactured Home Construction and Safety Standards. HUD wind zones apply to HUD-code manufactured homes; the listed 3-second-gust speed is a separate specification, not a direct equivalence to HUD zone criteria.

Coastal Installation

For hurricane-prone coastal sites, confirm the local required design wind speed, exposure and applicable wind zone before ordering; some locations require Zone III or higher site-specific loads.

Foundation & Anchorage

Site-specific foundation, tie-downs and continuous structural connections must be designed for local wind loads, uplift and overturning by a licensed professional.

Placement

Prepared, level foundation and delivery or crane access required

Permits & Local Approval

Buyer must confirm local permits, setbacks, foundation and utility requirements before delivery

Utility Connections

Final site connections must be completed and inspected by locally licensed trades where required

Structural Warranty

15+ year structural warranty

Delivery

Free standard delivery to the continental U.S. by flatbed, set by coordinated crane

Delivery Estimate

About 8–15 business days (Free Flatbed Delivery with Crane Set)

Electrical

110V/220V pre-wired, breaker panel, LED lighting, exterior weatherproof outlets

Foundation

Delivered ready to set on piers, slab, or ground-screw foundation

Construction

Heavy-gauge CorTen steel frame with insulated wall, floor & roof panels

Windows & Doors

Insulated dual-pane windows, insulated steel entry door, security shutters optional

Delivery method

Flatbed truck with crane

Straight approach (min.)

At least 80 ft

Access width (min.)

At least 12 ft

Overhead clearance (min.)

At least 15 ft along the route

Drop zone / setup area

crane pad 20 x 30 ft, level and firm, within 25 ft of the set point; no power lines within 20 ft of the lift path

Delivery note

Delivered on a 48–53 ft flatbed (about 75 ft overall) and set by crane, which Outback coordinates. Provide a level, firm 20 x 30 ft crane pad within 25 ft of the set point, with no power lines within 20 ft of the lift path.
